ROXOR

Its ancestors explored continents, roamed battlefields and helped build nations. We started with that rugged DNA then added modern innovation to bring you ROXOR—an off-road workhorse forged with all the passion and toughness its lineage demands. ROXOR is the old made new; a do it-all-industrial-strength stud meant to shatter conventions and challenge your idea of what an off-road vehicle can be.

Built on a no-nonsense, heavy-duty steel frame and body, ROXOR comes with an industry-best two-year standard warranty and—with a Mahindra 2.5L turbo diesel engine—3490 pounds of towing capacity.

Boasting nearly unlimited potential for customization, you can build your ROXOR from the ground up to meet your any need. For the trail, for the ranch, for the job, or just busting into the great unknown… add the accessories you need and make your ROXOR YOUR ROXOR.

Stop dreaming. Start Building.

SPEC SHEET
BUILD YOUR ROXOR


Hover to spin

ROTATE THE ROXOR

Vehicle Specs

  • Wheelbase
  • 96"
  • Base Curb Weight
  • 3035 lbs
  • Length
  • 148" (w/ spare 156”)
  • Width
  • 62"
  • Height
  • 75"
  • Ground Clearance
  • 9"
  • Fuel Capacity
  • 12 gal
  • Rear Payload Capacity
  • 349 lbs
  • Towing Capacity
  • 3490 lbs
  • Person Capacity
  • 2
  • Type
  • Turbo Diesel m2DiCR
  • Cylinders
  • 4 - 4stroke Compression Ign
  • Displacement
  • 2.5L / 152 cu. In.
  • Bore & Stroke
  • 88.9 x 101.6mm
  • Power
  • 62 HP @ 3200 rpm
  • Torque
  • 144 ft lbs @ 1400-2200 rp
  • Compression Ratio
  • 18.6 : 1
  • Cooling System
  • Liquid
  • Fuel System
  • Direct Injection
  • Transmission
  • 5 spd manual
  • Transfer Case
  • 2 Spd manual
  • Driveline
  • 2wd / 4wd
  • Full Floating Front Axle
  • 3.73 : 1
  • Full Floating Rear Axle
  • 3.73 : 1
  • Chassis Type
  • Boxed Steel Frame
  • Front Suspension
  • Rigid Leaf Spring w/ Stabilizer Bar
  • Rear Suspension
  • Leaf Spring w/ Shock Absorbers
  • Shock Absorbers
  • Double Acting Hydraulic
  • Dual Hydraulic Vac Assist
  • Std
  • Parking Brake
  • Std
  • Front Brakes
  • 11" Disc
  • Rear Brakes
  • 11" Drum
  • Steering
  • Hydraulic Pwr
  • Instrumentation
  • Single Gauge
  • Lighting / Headlights
  • Halogen
  • Battery
  • 72Ah / 12v
  • Alternator
  • 45 to 90 Amps
  • Power Port 12v
  • std
  • Storage
  • 2 seat boxes
  • Seating
  • 2
  • Tires
  • 235 / 70R16
  • Wheels / Steel
  • 16" - 5 x 5.5 lug
  • Wheels / Aluminum (Optional)
  • 16" - 5 x 5.5 lug
  • Carbon Black
  • Urethane
  • Classic White
  • Urethane
  • Fire Orange
  • Urethane
  • Tahoe Blue
  • Urethane
  • Custom
  • over 400 custom colors available, see your local ROXOR dealer
  • Max Speed
  • 55 MPH
  • Max Towing Speed
  • 15 MPH
  • Flat Tow Speed
  • 55 MPH *flat towing only with installed locking hub kit
  • Country of Assembly
  • USA
